luminum wire drawing process introduction
AMD-450/13SP Aluminium rod breakdown machine with dual take-up was independent research and development product of our company.It is one of the best-selling machines since 2009. The machine has a compact structure, wire straightness easy to adjust, good stability and many other advantages.
Technical parameters
Model SL-450/13SP wire drawing machine
1、Motor of drawing (kw) ：90kw 4pole
2、Dia. of wire in (mm) ：∅9.5
3、 Dia. of wire out (mm) ：∅1.78-∅3.0
4、Max. drawing times ：13
5、Max. speed (m/min)： 900
6、Dia. of speed-fixing wheel (mm)： ∅450
7、Lubricating and cooling mode： Spraying and semi-soaking
8、Case of host machine ：Cast and weld
9、Case of gear ：Cast
10、Case of water tank ：Weld
11、Mode of transmission ：Precision gear drive
12、Material of gear ：ZG 45 surface quenching
13、Material of shaft： Steel heat treatment
14、Bearing： LYC
15、Turret wheel ：Surface quenching
16、Weight (kg) ：4100
17、Overall dimension (mm) ：4150×1600×1100
Intelligent dual take up SP-III
1、 Motor of take up (kw)： 2×7.5
2 、Motor of small (kw)： 0.75
3、 Mode of wire arranging： Iron rod arranging
4、 Mode of control ：FC
5、 Diameter of disc (mm)： Standard ∅400/∅500
6、 Weight (kg) ：1800
7、 Overall dimension (mm) ：2370×1500×1342
Quality control
1. Checking raw material before producing.
2. Checking one by one before the assebling
3. Checking one by one during the production
4. Have the random inspection before the delivery.
Testing standard
Salt Spray test :after 72hours ,no corrosion on surface
No damage on espag rod surface.
Espag rod over hauling and found:
After 25000times repeatedly opening and closing ,espag rod parts have no distortion ,no deformation and do not affect the normal use of espag rod.
Our Advantages
a. Extensive production experience: we are specialized in all kinds of wire drawing machine with an experience of 10 years.
b. Complete production facilities: owning precision centerless grinding machine, straightening machine, fine polishing machine, precision lathe, milling and drilling machine, roller press and other advanced equipments. Our technicians will do regular scheduled maintenance on these machines to guarantee them work well.
c. High quality raw material: we mainly choose good supplier from big company, such as ABB , Siemens
d. Strict Physical/Chemical testing procedures: meeting the requirements of the product design and process, providing reliable testing data.
e. Short Delivery time: If one container 15-20 days.
g. Best after-sale service: Over 60% products are sold to the Southeast Asia, Middle East and Europe, and all products are trusted by domestic and foreign customers.
